Rolling Fire Rated Coiling DoorsFire Doors
Model Number: ERD10 and ERD11
Rolling Fire Door Closures
Our Rolling Fire Doors stop fire in its tracks saving property and, more importantly, lives. Our advanced fire door systems are designed to automatically activate your door in the event of smoke or fire. Once the door is in the closed position, this prevents the fire and smoke from migrating throughout the building, allowing occupants to safely evacuate.
Our rolling fire rated doors have become the clear and reliable choice for building owners and designers who demand the highest level of life safety and fire protection available. In addition, the cost of ownership is low because our advanced systems reset or auto open after a fire or power outage, saving time and money.
Although this door is specifically designed for fire rated openings, it also provides security and access control for use in openings that are not part of a required means of egress.
Our fire rated rolling doors are also available with an optional SmokeShield® package. This package adds smoke and draft control which conforms to UL1784, assuring that smoke with be compartmentalized with the fire and not spread throughout the facility.
A standard UL labeled fire door is available up to 13.5' wide by 12' high.
An oversized UL labeled fire door is available up to 60' wide by 40' high or 1,200 sq. ft.
For openings that fall outside of the standard construction, please contact us
Standard Materials and Finishes
• 22, 20 and 18 gauge galvanized steel:
‒ Exclusive GalvaNex™ finish in Gray, Tan, White or Brown provided as standard
• 20 gauge 300 series stainless steel:
‒ #4 finish
Stamped steel or cast iron endlocks are provided per UL procedure.
Click here for additional material and finishes options and information.
Finish/gauge availability varies. Contact us for detailed finish/gauge availability.
Fire doors can be installed face of wall or between jambs on an interior or exterior wall. Acceptable wall types include masonry, structural steel jambs and drywall construction with structural steel or wood studs.
Need to see clearances and mounting details? Enter your opening dimensions into our Drawing Generator, and get custom generated drawings of your door with all the details.
Fire Door Drawing Generator
SmokeShield® Seal Package
Often required by local building codes, our smoke seal adds smoke and draft control.Learn More
Optional safety devices on provide a visual and/or audible advanced warning when the door is about to close .
Battery Back Up Devices
Available for motor, chain and crank operators, these devices prevent fire doors from closing from a power failure.Learn More
Firefly & Firefly BB Release Device
Optional device that ties in to a building alarm system and closes a FireGard fire door upon alarm activation, rather than by melting its fusible link.
Safely and conveniently test and reset the functionality of the fire door at floor level. May be flush or recess mounted.
AtmoShield™ Powder CoatingTextured powder coat finish that combats the environments harsh wear and tear. This finish provides a thicker, more scratch resistant coat for added product protection.
Hood and Operator Covers
Metal cover to protect the coil or operator from exterior weather, debris or to meet OSHA or UL 325 safety requirements.Learn More
SpectraShield™ Powder Coating
Polyester finish in more than 180 colors for durability, aesthetics, superior finish life and cost effectiveness.Learn More
Trim PackageIn applications where exterior aesthetics are important, such as hotels, condominiums, convention centers and parking garages, the addition of a trim package can cover unsightly hardware and contribute to the building's architecture.
High Cycle SpringsHeavy duty springs manufactured to withstand cycles of 100,000.
Seismic Performance Validation
We can provide project specific seismic calculations for all coiling doors that are mounted Face of Wall to steel or masonry. Seismic performance validation is per ASCE 7-05.
Entrapment Protection Devices
Entrapment protection devices ensure that a motorized door or grille will not close on an object. If an object enters path of closure, the entrapment protection device will stop the door or grille from closing and return it to the fully open position.
Guide-Mounted InterlocksAn electrical cutout switch to prevent motor operation if locking device is not first disengaged.
Rolling Door Protector (RDP)
The RDP eliminates costly fork truck damage to coiling doors by creating a physical barrier at the top of the door that absorbs impacts.
Static Wind LoadCan be configured to withstand the full range of specific wind load requirements including missile impact ratings.
